20m3 high pressure hydrogen storage vessel

Author:


This serie product is applicated in the gas storage, which is under the high pressure enviroment. The vessels are strong and durable and can be designed to be abrasion resistant, corrosion resistant or with alternate metallic liners for added strength.

20m3 high pressure hydrogen storage vessel



HXCHEM is an ASME code vessel shop and carries a Certificate of Authorization to fabricate pressure vessels to ASME Section VIII, Div. We offer extensive expertise in the mechanical design of ASME pressure vessels that will meet rigorous quality standards and procedures and are guaranteed for a long, trouble-free vessel life.



Introduction

This serie product is applicated in the gas storage, which is under the high pressure enviroment. The vessels are strong and durable and can be designed to be abrasion resistant, corrosion resistant or with alternate metallic liners for added strength.

Pressure Vessels

stainless steel clad pressure vessel manufacturers / custom pressure vessels / large pressure vessel manufacturers / advanced pressure vessel



  • Vertical and horizontal gas storage tanks, liquid storage, and vacuum tanks, etc.

  • The medium is air, hydrogen, nitrogen, oxygen, natural gas, water, liquefied gas, oil, refrigerant, etc.

  • The product meets the requirements of various standards such as ASME, PED, GB150.

  • Material: CS; SS; Nickel alloy material; Titanium; Hastelloy C276 cladding.



At Alloy Engineering, we have the expertise to customize pressure vessels to your specifications. We can assist with critical issues such as material selection and design optimization. We also offer specialized design and welding techniques for these demanding high temperature and corrosive Applications.






Model

HV

Norminal volume

23m3

Material

CS, SS, other alloy lined

Design pressure

85 bar

Design temp.

-196~350℃

ASME Pressure Vessels

Product Features

* Type 3 Pressure Vessel.

* Large scale industrial scale production;
* GB, ASME design and manufacture certificate.
* Max pressure: 200 bar; Max temperature up to 350 ℃;
* We offer carbon steel, stainless steel, or most exotic alloys such as Hastelloy, Monel, or Inconel;
* When the pressure is large, cladding plates could be considered, including base material for strength and clad material for anti-corrosion. Reduce costs for you!
* Internal cooling coil, vent port, liquid / powder charging, dip tube, thermowell, safety rupture disc, pressure safety valve, flush bottom outlet, baffles, light & sight glass, handhole / manhole etc.* We offer various internal and external finishes for our products.

* Lugs or floor stand leg support.






Product Paramenters



Norminal volume

100L-200 m3

Material

CS, SS, other alloy lined

Design pressure

-1~200 bar

Design temp.

-40~350℃

Base Thickness

6~160mm

Clad Thickness

3~10mm

Max Length

16 m

Max Diameter

6 m

Max weight

200 tons

Shape

Vertical or horizontal

Head type

Semi-elliptical, Dished type,

Hemispherical, Flat type

Jacket

Dimpled, Half-pipe, Std.

Heating type

Oil electric heating; Oil heating; Steam heating

Note: If the diameter exceeds 6,000mm, it need to be fabricated on the site.
If the unit weight exceeds 200tons or the total length exceeds40m, segmented transport and field welding will be required.

Customization



Customized Specifications
If there has special process requires,HXHCEM will also customize for you!
Pls list your basis process parameters like follows:
1. Vessel volume
2. Operating Temperature
3. Operating Pressure
4. Vessel Material / contacting components material
5. With heating device or not.
6. Internal cooling coil or not, exchange area?

7. Support method
8. Your other requests
......Contact us
We'd like to help you to accomplish your plans.
